Hafele 405.82.118 Sliding Door Hardware, EKU Clipo 16 H Mixslide, set For thin cabinet tops, for wooden sliding doors, for door weights up to 16 kg, for door heights up to 1,400 mm, for 2 doors
Product Information
Description
Hafele 405.82.118 Sliding Door Hardware, EKU Clipo 16 H Mixslide, set
For thin cabinet tops, for wooden sliding doors, for door weights up to 16 kg, for door heights up to 1,400 mm, for 2 doorsFor 2 doors, with installation instructions Door weight : (35 lbs.) 16 kg Door height : (55 1/8") 1400 mm Door width : (39 3/8") 1000 mm Door thickness : (5/8 and 3/4") 16 - 19 mm Height adjustment : (+1/16-1/32") +2/-1 mm Running gear : with clip-mounting, plastic rollers with metal axles Supplied with : 4 Running gears
4 housing pieces
1 soft stop
2 track stoppers
1 guide
Optional items:
Service Port, EKU Clipo 16 H Mixslide
Service Port, EKU Clipo 16 H Mixslide
Soft Closing Mechanism, EKU Clipo 16Specifications
