Manufacturer: Hafele
Item: 421.59.521
Product Title: Optional Easy Close Kit, Accuride 115RC Linear Motion Track System, 265 Weight Capacity,
Category: Optional Easy Close Kit, Accuride 115RC Linear Motion Track System, 265 Weight Capacity, 421.59.521
Item Details …
- Linear Motion Track System is a unique movement solution consisting of lightweight aluminum tracks and re-circulating ball carriages which provide guidance, movement and positioning for screens, panels, partitions or other components in industrial, commercial and institutional applications.
- Track available in two lengths: 1.2 m (47") and 2.4 m (94")
- Corrosion-resistant track may be cut down to the desired length or butted together to extend to any length.
- Re-circulating ball carriages in two options:
- Stainless steel ball bearing carriage – provides the greatest load capacity
- Polymer ball bearing carriage – grease-free with smooth and quiet movement
- Tracks have drilling marks for both the fixing holes and end stops.
- Product type : Optional Easy Close Kit
- Load bearing capacity : 130.00 kg
- Load bearing capacity : Up to 265 lbs
- Material : Plastic
- Installation : Screw fixing
- Installation reference : Linear Motion Track System is a unique movement solution consisting of lightweight aluminum tracks and re-circulating ball carriages which provide guidance, movement and positioning for screens, panels, partitions or other components in industrial, commercial and institutional applications.Track available in two lengths: 1.2 m (47") and 2.4 m (94")Corrosion-resistant track may be cut down to the desired length or butted together to extend to any length.Re-circulating ball carriages in two options:Stainless steel ball bearing carriage – provides the greatest load capacityPolymer ball bearing carriage – grease-free with smooth and quiet movementTracks have drilling marks for both the fixing holes and end stops.
Additional Information …
Weight capacity is based on the type and number of ball carriages. See the Load Rating tab for more information. Due to the extensive variety of applications and possible orientations for this product, we recommend that customers first test this product in the intended application. This product is not recommended for high-torque applications.
