Hafele 550.47.931 Marking Jig For drawer side height 89 mm and 185 mm

Product Information

• Description

  Manufacturer: Hafele
  Item: 550.47.931

  Product Title: Marking Jig, for Grass Vionaro Drawer System, For drawer side height 89 mm and 185 mm

  Category: Marking Jig, for Grass Vionaro Drawer System, For drawer side height 89 mm and 185 mm

  Item Details …

  - Product type : Marking Jig

  - Area of application : For exact marking of the drilled holes for the Vionaro

  - Drawer length : 21"

  - Material : Plastic

  - Supplied with:

  - 2 pcs each

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 8.31



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_8.12-8.13.pdf



• Required Products & Optional Accessories

  Optional Accessories:



  • Front Panel Kits for Grass Vionaro, for Side Height: (3 1/2") 89 mm
  • Front Panel Kits for Grass Vionaro, for Side Height: (7 1/4") 185 mm
