Hafele 551.54.827 MX 50 kg Drawer Set, steel, champagne, profile height=92mm, length=600mm, 55154827, 551-54-827Zoom

Hafele 551.54.827 Matrix Box P50, drawer side height 92 mm, load bearing capacity 50 kg Champagne, Length: 600 mm (23 5/8")

$52.20$104.40You Save: $52.20 (50%)
Item# Hafele-551-54-827
Availability: in stock
CLEARANCE 50% OFF (non refundable)
Available Quantity: 471 until supplies last

Product Information

  • Description

    Manufacturer: Hafele
    Item: 551.54.827

    Product Title: Drawer side runner system, Häfele Matrix Box P50, drawer side height (3 5/8") 92 mm, load bearing capacity (110 lbs) 50 kg, Load bearing capacity 50 kg, Häfele Matrix Box P50 drawer set, drawer side height 92 mm, Champagne, Length: 600 mm (23 5/8")

    Category: Drawer side runner system, Häfele Matrix Box P50, drawer side height (3 5/8") 92 mm, load bearing capacity (110 lbs) 50 kg, Load bearing capacity 50 kg, Häfele Matrix Box P50 drawer set, drawer side height 92 mm

    Item Details …

    -     Load bearing capacity : 50.00 kg

    - Load bearing capacity : 110 lbs

    - Material : Steel

    - Height (inch) : 3 5/8"

    - Type of pull out : Full extension, with integrated Smuso soft closing mechanism and self closing mechanism, with integrated rear panel fitting

    - Drawer side height : 92.00 mm

    - Front fixing brackets : not included

    - Adjustment facility : Convenient height and side adjustment from above when installedHeight adjustment ± 2.5 mmSide adjustment ± 1.5 mm

    - Installation : Mounting and disassembly of the panel without tools

    - Order reference

    - Please order recommended cylindrical head screw Cat. No. 013.20.930 for runner installation separately.

    - Front fixing brackets for drawer not included in scope of delivery, please order separately.

    - Supplied with:

    - 1 left and 1 right drawer side with rear panel fitting

    - 1 left and 1 right cabinet runner

    - 1 left and 1 right cover cap with Häfele logo relief

  • Data Sheet

  • Product Resources

  • Specifications

    For detailed PDF specifications, click:
    Hafele Catalog Page: selection_8.4-8.4.pdf

  • Required Products & Optional Accessories

    Optional Accessories:

    • Euro screw, with Special Cylinder Head, #2 Pozi Drive, Bulk Pack
    • Drawer Front Fixing Bracket, Häfele Matrix Box P
    • Panel holder, for Internal Standard Drawer, Häfele Matrix
    • Front Panel Holder, for Internal Deep Drawer, Häfele Matrix
    • Stabilizing Plate, Front panel stabilising plate, Häfele Matrix Box P
    • Spacer, For Häfele Matrix Box P internal drawer and internal pull out
    • Replacement Cover Cap, for Häfele Matrix Box P Plus drawer sides
    • Drawer press, Pressomat 200, for assembly of Moovit drawers
    • Panel holder, Häfele Matrix Box P
    • Insertion Tool, Häfele Matrix Box P
    • Marking Gauge, Häfele Matrix Box P
    • Gallery Rail, Round, Häfele Matrix Box P
    • Gallery Rail, Rectangular, Häfele Matrix Box P
    • Cross Front Rail, Round, Häfele Matrix Box P
    • Cross Rail Holder, Round, Häfele Matrix Box P
    • Cross rail, Rectangular
    • Cross rail holder, Rectangular, Häfele Matrix Box P

  • Brand PDF Catalogs

Cannot find your product? click: Help!. Our product experts will assist you.

Quick Metric Conversions: 25mm = 1 inch (approx), 2.5cm = 1 inch (approx), 96mm = 3.75 inches
