Hafele 833.74.371 LED2070 12 volt direct current 9.6 watts per meter 2700K-5000K CRI90 50 meters

Product Information

• Description

  Manufacturer: Hafele
  Item: 833.74.371

  Product Title: LED strip light, Häfele Loox5 LED 2070, 12 V, multi-white, (5/16") 8 mm, 2 x 120 LEDs/m, 9.6 W/m, Warm white 2700 K to cool white 5000 K, (1968 1/2") 50 m

  Category: LED strip light, Häfele Loox5 LED 2070, 12 V, multi-white, (5/16") 8 mm, 2 x 120 LEDs/m, 9.6 W/m

  Item Details …

  -

  - Optimized light mixture

  -

  - Cool white and warm white LEDs in the smallest of spaces

  - Optimal light mixture without flickering

  - Color temperature : 2700?–?5,000 K

  - Light color : Warm white to cool white

  - Nominal voltage : 12.00 V

  - Wattage/m : 9.60 W

  - Luminous flux/m : 825?–?930 lm

  - Luminous efficacy : 86?–?97 lm/W

  - Max. strip length (visual) : 3.50 m

  - Energy efficiency class : F

  - Height (inch) : 1/16"

  - Width (inch) : 5/16"

  - Dimmable : yes

  - Area of application : Store fixtures, Storage spaces, Working areas, Reading areas

  - Material : Plastic

  - Color : White

  - Strip width : 8.00 mm

  - Strip height : 1.30 mm

  - Section length : 25.00 mm

  - Life time : L80/B10: >50,000 h

  - Color rendering index Ra : >90

  - Color rendering index R9 : >50

  - Degree of protection : IP20

  - Installation : Self-adhesive

  - Order reference

  - Please order lead separately.

  - Aluminum profile is recommended from 9.6 W/ m.

  - Color control via Häfele Connect Mesh 6-way distributor with multi-white adapter and remote control or smartphone. Please order separately.

  - Supplied with:

  - 1 roll


  Additional Information …

  Maximum strip length (visual) describes a strip section with a visually imperceptible drop in luminous flux of max. 30%. Please note: A strip section with a new power supply that follows immediately is noticeably brighter.Max. wattage-dependent strip length on the driver, see technical data for LED strip lights.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  Fitting instructions for Loox5 LED 2064 / 3070 / 3044 / 3047 / 3049

  Safety Notes for LED Strip Lights

  UL Certificate E473379 - US

  Loox – Electrical Code Compliance



• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  Lead, Häfele Loox5 for LED-Band multi-white (5/16") 8 mm, 12 V (choose one):


  • 3.5 A, 20 AWG, Length: 100 mm (4") 3.5 A, 20 AWG, Length: 2000 mm (78 3/4")

    833.93.742 833.95.702

    Click to order Click to order



  Distributor, Häfele Connect Mesh 12 V with switching function 2-pin (monochrome) (choose one):


  • with programmable switching input, Voltage 12 V, max. connected wattage 60 W

    850.00.042

    Click to order



  Adapter, Häfele Loox5, multi-white, for Häfele Connect Mesh 6-way distributor (choose one):


  • for Häfele Connect Mesh 6-way distributor, 60 W, Voltage 12 V, max. connected wattage 60 W

    833.95.745

    Click to order



  Optional Accessories:



  • Interconnecting lead, Häfele Loox5 for LED strip light, multi-white, (5/16") 8 mm
  • Clip connector, Häfele Loox5 for LED strip light, multi-white, 8 mm (5/16")
  • Corner connector, Häfele Loox5 for LED strip light, multi-white, 8 mm (5/16")
  • Remote control, Häfele Connect Mesh
  • Wall mounted push button, Häfele Connect Mesh
