Hafele 361.42.391 Hinge, for Wood Doors and Lids Black

Product Information

• Description

  Manufacturer: Hafele
  Item: 361.42.391

  Product Title: Hinge, for Wood Doors and Lids, Black

  Category: Hinge, for Wood Doors and Lids,

  Item Details …

  - Material : SteelBushing: Plastic

  - Color/finish : Black

  - Flange thickness : 2.00 mm

  - Number of drill holes : 5.00

  - Product type : Hinge

  - For door thickness min. : 9/16"

  - Area of application : For rebated doors

  - Version : With press-fit bushing

  - Supplied with:

  - Bushings and screws

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 9.91



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_9.85-9.89.pdf

  Hafele 361.42.391, 361-42-391, 36142391, 361.42


  Specifications/Hafele Catalog - Page# FC9.95: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Hinges & Stays Catalog Return to: All Hafele Catalogs
