Hafele 403.50.941 Slido R-Aluflex 80W Running Gear and Guide Set, supplied with 2 running gears and 2 guides for 1 wood door (1 kit), 40350941, 403-50-941Zoom

Hafele 403.50.941 Sliding Door Hardware, Woodflex 80, Set For room-high wooden sliding doors, compatible with Silent Aluflex, with soft closing mechanism (optional), for door weights up to 80 kg, for door heights up to 3,000 mm, For 1 doors

$119.58$149.48You Save: $29.90 (20%)
Item# Hafele-403.50.941
Availability: in stock (Qty 61, more available by ... 12/31/24)

Product Information

  • Description

    Manufacturer: Hafele
    Item: 403.50.941

    Product Title: Sliding Door Hardware, Slido R-Aluflex 80W, set, For room-high wooden sliding doors, compatible with Slido R-Aluflex 80A, with soft closing mechanism (optional), for door weights up to 80 kg, for door heights up to 3,000 mm, for 1 door

    Category: Sliding Door Hardware, Slido R-Aluflex 80W, set, For room-high wooden sliding doors, compatible with Slido R-Aluflex 80A, with soft closing mechanism (optional), for door weights up to 80 kg, for door heights up to 3,000 mm, for 1 door

    Item Details …

    -     Number of doors per system max. : >4

    - Number of doors : 1.00

    - For door material : wood

    - Model : 80W

    - Soft closing mechanism : with soft and self closing mechanism

    - Running gear version : Plastic coated ball bearingbottom running, 1 roller

    - For door weight : ?80 kg

    - For door width : 500?–?1,500 mm

    - Material/finish : Running gear: Steel, Guide rollers: Plastic, Axis: Steel

    - Controller installation options : Ceiling installation

    - Adjustment facility : Height adjustment: ±5 mm, –5/+6 mm on running gear (TS 20 drive)

    - For door thickness min. : 7/8"

    - For door thickness max. : 1 7/16"

    - Area of application : For 1 doors

    - Suitable for : Room-high solutions

    - For door height : ?3,000 mm

    - Running position : Bottom

    - Installation : Running track for recessed mounting or glue fixing

    - Installation reference : The roller is inserted from below and screwed to the door leaf through the middle hole.

    - Door processing : for screw fixing

    - Order reference

    - Please order running and guide track, soft closing mechanism and other accessories separately.

    - Supplied with:

    - 2 running gears, 2 guides


    Additional Information …

    Compatible with the Aluflex system. More application options can be found under Häfele Silent Aluflex 80.



    The door material or door construction must be selected in accordance with the requirements on site:Consider material strength so that the roller cannot sink into the material or split it.Only a little material remains on the left and right hand side of the roller recess. The roller may break away if the front or rear panel is subjected to a certain load.

  • Data Sheet

  • Product Resources

  • Specifications

    For detailed PDF specifications, click:
    Hafele Sliding Door Catalog Page: selection_1.152-1.153.pdf

    Hafele 403.50.941 Hafele Woodflex 80 running gear and guide set, suppl
    • Hardware > Hardware Accessories
    • Hardware,Hafele,50-500
    • Brand: Hafele
    • Part#: 403.50.941
    • Condition: new

  • Required Products & Optional Accessories

    Optional Accessories:

    • Wall compensating profile, Hawa
    • Wall Connection Profile, For screw fixing
    • Track Cleaning Brush Set, For Cleaning Running Track, without Häfele Logo
    • Brush Seal, Self-Adhesive
    • Cover Cap, for Slido R-Aluflex 80A/R-Aluflex 80W
    • Roller Pin, for connecting the guide/running tracks

  • Brand PDF Catalogs





Cannot find your product? click: Help!. Our product experts will assist you.

Quick Metric Conversions: 25mm = 1 inch (approx), 2.5cm = 1 inch (approx), 96mm = 3.75 inches
